Seating Pins DIN 6321

Key Features

  • Known as Location, Locating or Seating Pins
  • In Tool steel, hardened and ground, head tolerance is h9
  • Seating Pins are commonly used as bearing surfaces for tools, jigs and fixtures.
  • DIN 6321

Seating Pins DIN 6321 (Flat Headed Location Pins)

The most common location pin is the seating location pin to DIN 6321, these have a chamfered head which allows for easier location, they have a small and large part of the body which allows for press fit of the narrow part of the pin, with the larger head offering a clearance fit with the work piece. Quite frequently Seating Location Pins are used as bearing surfaces for tools, jigs and fixtures. Seating pins can also be used for height setting.

How to Buy

Please choose the pin you require, before entering a quantity and clicking 'Add to Cart'. The diameters shown are the pin diameters, for the head size, tolerances and other dimensions, please download the catalogue from the tab above.

DIN 6321 Seating Pin (Pin diameter 4mm x Pin Length 6mm)
DIN 6321 Seating Pin (Pin diameter 4mm x Pin Length 6mm)
Product Number: SP1-3622
List Price: £4.72
Your Price £4.72

DIN 6321 Seating Pin (Pin diameter 6mm x Pin Length 9mm)
DIN 6321 Seating Pin (Pin diameter 6mm x Pin Length 9mm)
Product Number: SP2-3622
List Price: £5.33
Your Price £5.33

DIN 6321 Seating Pin (Pin diameter 8mm x Pin Length 12mm)
DIN 6321 Seating Pin (Pin diameter 8mm x Pin Length 12mm)
Product Number: SP3-3622
List Price: £6.87
Your Price £6.87

DIN 6321 Seating Pin (Pin diameter 12mm x Pin Length 18mm)
DIN 6321 Seating Pin (Pin diameter 12mm x Pin Length 18mm)
Product Number: SP4-3622
List Price: £10.27
Your Price £10.27
