Metric Bullet Nose Dowels

Key Features

  • Precision Ground Locating System
  • Metric Sizes
  • Case Hardened
  • Black Oxide Finish
  • Concentric to 0.0005" TIR
  • -0.0003 Body Tolerance

Metric Bullet Nose Dowels

Bullet Nose Dowels (BND) are used in conjunction with a Bullet Nose Liner (BNL) to create a precision locating system. The Bullet Nose Dowel is easily located in the corresponding liner thanks to its ‘bullet nose’ feature. The pins head and body diameters are ground concentric to within 0.0005” TIR. Two work pieces in a jig can be accurately located using both the Bullet Nose Dowel and the mating Bullet Nose Liner.

Bullet Nose Dowel 6MM Diameter
Bullet Nose Dowel 6MM Diameter
Product Number: BNDM600
List Price: £2.96
Your Price £2.96

Bullet Nose Dowel 8MM Diameter
Bullet Nose Dowel 8MM Diameter
Product Number: BNDM800
List Price: £2.99
Your Price £2.99

Bullet Nose Dowel 10MM Diameter
Bullet Nose Dowel 10MM Diameter
Product Number: BNDM1000
List Price: £3.61
Your Price £3.61

Bullet Nose Dowel 12MM Diameter
Bullet Nose Dowel 12MM Diameter
Product Number: BNDM1200
List Price: £4.25
Your Price £4.25
