Diamond Bullet Nose Pins Imperial

Key Features

  • Precision Ground Location System
  • Diamond (Relieved) Pin
  • Case Hardened
  • Black Oxide Finish
  • Concentric to 0.0005" TIR
  • Imperial (Inch) Sizes

Bullet Nose Pins - Diamond Type in Imperial

Diamond Bullet Nose Pins are also known as relieved pins. Bullet nose pins are used with a mating liner bush to create an accurate alignment and locating system. Using diamond locating pins prevents binding of the work pieces. For simple installation, the OD of the pin body and the liner are the same, giving the option of one pass machining of both pates. The pins head and body are concentric to 0.0005 TIR.

Diamond Bullet Nose Pin 1/4" Pin
Diamond Bullet Nose Pin 1/4" Pin
Product Number: BNP2499
List Price: £3.34
Your Price £3.34

Diamond Bullet Nose Pin 5/16" Pin
Diamond Bullet Nose Pin 5/16" Pin
Product Number: BNP3124
List Price: £7.97
Your Price £7.97

Diamond Bullet Nose Pin 3/8" Pin
Diamond Bullet Nose Pin 3/8" Pin
Product Number: BNP3748
List Price: £9.29
Your Price £9.29

Diamond Bullet Nose Pin 1/2" Pin
Diamond Bullet Nose Pin 1/2" Pin
Product Number: BNP4998
List Price: £9.88
Your Price £9.88

Diamond Bullet Nose Pin 3/4" Pin
Diamond Bullet Nose Pin 3/4" Pin
Product Number: BNP7498
List Price: £13.81
Your Price £13.81

Diamond Bullet Nose Pin 1" Pin
Diamond Bullet Nose Pin 1" Pin
Product Number: BNP9998
List Price: £18.01
Your Price £18.01
