Alignment L-Pins

Key Features

  • L-Shaped Handle
  • Ground Hardened Pin (-0.0005)
  • Case Hardened
  • Black Oxide Finish
  • Drilled Hole for Cable Assembly
  • Accurate Alignment
  • Use with BONEHAM Bushes and Slotted Bushes

L Shaped Alignment Pin

L-Pins are used to align location devices in Jigs and Fixtures. They are precise (-0.0005) and quick to remove. The L shaped handle allows for greater grip and removal. The L shape is ideal when working space is restrictive. Alignment pins can be used with a variety of BONEHAM bushes. Press Fit, Serrated or Slotted type bushes would complete and accurate alignment solution. The handle has a 1/8" cross drilled hole to connect the pin to the jig with an optional cable.

Alignment L-Pin in Imperial (Inch)
Alignment L-Pin in Imperial (Inch)
Diameter
Length

Alignment L-Pin in Metric
Alignment L-Pin in Metric
Diameter
Length
