Koenig CV Series

Key Features

  • Aluminium Sleeves
  • Anodized or Alodine Finish
  • Stainless Steel Balls
  • Special wax film lubrication

Koenig CV Series Plugs

Following the same concept as the MB Series. The CV plug operates a pressure/expand principle. Each plug consists of a ball, as the expanding element, and a cup-shaped expansion sleeve. Forcing the ball into the sleeve causes the sleeve to expand outward. The serrations on the outside of the sleeve dig into the base material to provide a secure anchorage. The ball is set when it is flush with or slightly below the top of the sleeve. The top of the sleeve constricts slightly and prevents the ball from coming out.

CV Plugs are available in Aluminium and Stainless Steel. Aluminium sleeves feature either Anodized or Alodine chromate options.

For more details on the Koenig Expander range and all relevant drawings, please visit Boneham's dedicated Koenig Expander site www.koenigexpander.co.uk

The Koenig Expander is a safety critical component and it’s important for our Technical Sales Team to understand your application. Therefore online sales are only available to account customers. Please contact our Technical Sales Team.
